Will a window air conditioner fit my window? Sizes of every ENERGY STAR model
Cabinet width, height and depth of 510 ENERGY STAR window air conditioners, filtered by your window, plus the maker minimum window sizes for common units.
Cabinet sizes from ENERGY STAR's certified product data; window minimums from maker spec sheets and manuals. We have not installed these units ourselves. How we research | How links work
The short answer
It fits only if your window opening is wider than the unit's cabinet plus its side panels, and your raised sash leaves more clear height than the cabinet. Makers set the window minimum well above the cabinet: TCL's 8,000 Btu unit has an 18.6 inch cabinet but needs a 23 inch window, and Midea's U 8,000 Btu needs 22 inches and 13.75 inches of clear height. The 510 ENERGY STAR window models below come in 299 cabinet sizes, and 27 of those are under 18 inches wide.
Your window
Measure the inside of the frame from side to side, and the clear height with the lower sash raised as far as it goes.
Checking the table
Cabinets narrower and shorter than your window are shown in the table below.
Every ENERGY STAR window air conditioner, narrowest first
510 certified window models, grouped where one brand sells the same cabinet under several model numbers (299 rows). 145 rows are under 20 inches wide. Mounting type is ENERGY STAR's own field. Through-the-wall units are left out.
The GE Profile AHTR12ACH2, GE Profile AHTR14AC*# rows list a 10.6 inch width, far narrower than any other window unit, so check the maker's installation guide before relying on it.
Correction: ENERGY STAR lists the GE Profile AHTR10ACH2 as 10.6 inches wide. GE's own AHTR10AC page gives 20.5 inches wide, 13.9 inches high and 19.9 inches deep, with a window from 26.375 to 40.5 inches wide and at least 14.0625 inches high, so the table uses GE's figures for this model. The AHTR12 and AHTR14 rows still show ENERGY STAR's width because we have no GE figure for them yet.
| Brand and model | Btu | Width (in) | Height (in) | Depth (in) | Weight (lb) | Volts | Mounting (ENERGY STAR) | Source |
|---|---|---|---|---|---|---|---|---|
| GE Profile AHTR12ACH2 | 12,200 | 10.6 | 14 | 19.9 | 68 | 115 | Does not straddle | ENERGY STAR |
| GE Profile AHTR14AC*# | 13,500 | 10.6 | 14 | 19.9 | 103 | 115 | Does not straddle | ENERGY STAR |
| Hisense WCT06W25A | 6,000 | 15.9 | 11.8 | 13.8 | 35.3 | 115 | Does not straddle | ENERGY STAR |
| Whirlpool WHAW061CX | 6,000 | 16 | 12 | 13.1 | 33.1 | 115 | Straddles window | ENERGY STAR |
| BLACK+DECKER BDM05C | 5,000 | 16 | 12.1 | 13.3 | 30.2 | 115 | Does not straddle | ENERGY STAR |
| Brothers 102372 | 5,000 | 16 | 12.1 | 13.3 | 30.2 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWC055TF1 / FHWC056TF1 | 5,000 | 16 | 12.1 | 13.3 | 30.2 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW05R1KWT-B / MAW05R1VWBL-T / MAW05R1VWWT-T / MAW05S1KWT-A +1 more | 5,000 | 16 | 12.1 | 13.3 | 30.2 | 115 | Does not straddle | ENERGY STAR |
| Noma 143-1378-6 | 5,000 | 16 | 12.1 | 13.3 | 30.2 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV5000 | 5,000 | 16 | 12.1 | 13.3 | 30.2 | 115 | Does not straddle | ENERGY STAR |
| Vissani VAW05V1KWT | 5,000 | 16 | 12.1 | 13.3 | 30.2 | 115 | Does not straddle | ENERGY STAR |
| BLACK+DECKER BDM06C | 6,000 | 16 | 12.1 | 13.3 | 31.6 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWC065TF1 / FHWC066TF1 | 6,000 | 16 | 12.1 | 13.3 | 31.6 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW06S1KWT-A / MAW06S1VWBL-T / MAW06S1VWWT-T / MAW06V1KYWT-S +1 more | 6,000 | 16 | 12.1 | 13.3 | 31.6 | 115 | Does not straddle | ENERGY STAR |
| Noma 143-1379-4 | 6,000 | 16 | 12.1 | 13.3 | 31.6 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV6000 | 6,000 | 16 | 12.1 | 13.3 | 31.6 | 115 | Does not straddle | ENERGY STAR |
| Seasons SW06VB1 | 6,000 | 16 | 12.1 | 13.3 | 31.6 | 115 | Does not straddle | ENERGY STAR |
| Vissani VAW06V1KWTS | 6,000 | 16 | 12.1 | 13.3 | 31.6 | 115 | Does not straddle | ENERGY STAR |
| BLACK+DECKER BDM078C | 7,800 | 16 | 12.1 | 13.3 | 33.1 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWC074WF1 / FHWC076WF1 | 7,800 | 16 | 12.1 | 13.3 | 33.1 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW08S1KWT-A / MAW08V1SWBL-T / MAW08V1SWWT-T / MWEUWA-08CRFN8-BCM7 | 7,800 | 16 | 12.1 | 13.3 | 33.1 | 115 | Does not straddle | ENERGY STAR |
| Noma 143-1380-8 | 7,800 | 16 | 12.1 | 13.3 | 33.1 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV8000 | 7,800 | 16 | 12.1 | 13.3 | 33.1 | 115 | Does not straddle | ENERGY STAR |
| Seasons SW08VB1 | 7,800 | 16 | 12.1 | 13.3 | 33.1 | 115 | Does not straddle | ENERGY STAR |
| Vissani VAW08V1AWTS | 7,800 | 16 | 12.1 | 13.3 | 33.1 | 115 | Does not straddle | ENERGY STAR |
| TCL T05WV9M / T05WV9MB / T05WV9R / T05WV9RB +4 more | 5,000 | 16 | 12.5 | 15.5 | 41.9 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW050EX | 5,000 | 16 | 12.5 | 15.2 | 41.9 | 115 | Straddles window | ENERGY STAR |
| Hisense AHW0823TW1W | 8,000 | 18.5 | 13.2 | 18.9 | 44.5 | 115 | Does not straddle | ENERGY STAR |
| Noma iQ 143-0087-4 | 8,000 | 18.5 | 13.2 | 18.9 | 44.5 | 115 | Does not straddle | ENERGY STAR |
| Richmond RMV08A10A | 8,000 | 18.5 | 13.2 | 18.9 | 44.5 | 115 | Does not straddle | ENERGY STAR |
| Hisense AW1023TW1W | 10,000 | 18.5 | 13.2 | 18.9 | 46.3 | 115 | Does not straddle | ENERGY STAR |
| Noma iQ 143-0088-2 | 10,000 | 18.5 | 13.2 | 18.9 | 46.3 | 115 | Does not straddle | ENERGY STAR |
| Richmond RMV10A10A | 10,000 | 18.5 | 13.2 | 18.9 | 46.3 | 115 | Does not straddle | ENERGY STAR |
| GE Profile PWDV08W**# | 8,000 | 18.5 | 13.6 | 19 | 43.2 | 115 | Does not straddle | ENERGY STAR |
| GE Profile PWDV10W**# | 10,000 | 18.5 | 13.6 | 19 | 45.1 | 115 | Does not straddle | ENERGY STAR |
| GE PWJV08W**# | 8,000 | 18.6 | 12.6 | 15.3 | 46.2 | 115 | Does not straddle | ENERGY STAR |
| TCL T06WV9R / T06WV9RB / W6WC72 / W6WC72-B | 6,000 | 18.6 | 13.3 | 17.7 | 45.2 | 115 | Straddles window | ENERGY STAR |
| TCL T08WV3S / T08WV9S / T08WV9SB / W8WC72 +1 more | 8,000 | 18.6 | 13.3 | 17.7 | 41.9 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW081CX | 8,000 | 18.6 | 13.3 | 17.7 | 43 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW101CX | 10,000 | 18.6 | 13.3 | 17.7 | 43 | 115 | Straddles window | ENERGY STAR |
| BLACK+DECKER BD08NWES | 8,000 | 18.6 | 13.5 | 19.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| Danby DAC080EBIBDB | 8,000 | 18.6 | 13.5 | 19.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| ELEMENT EHWR08BE | 8,000 | 18.6 | 13.5 | 19.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW085WE1 | 8,000 | 18.6 | 13.5 | 19.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| Keplerx KARC8RSVE1 | 8,000 | 18.6 | 13.5 | 19.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW081WA | 8,000 | 18.6 | 13.5 | 19.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW08RV1CWT / MAW08S1VWT-A / MAW08S1VWWT-T / MWCUWA-08CRFN8-BCN10 | 8,000 | 18.6 | 13.5 | 19.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| BLACK+DECKER BD10NWES | 10,000 | 18.6 | 13.5 | 19.6 | 46.1 | 115 | Does not straddle | ENERGY STAR |
| ELEMENT EHWR10BE | 10,000 | 18.6 | 13.5 | 19.6 | 46.1 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW105WE1 | 10,000 | 18.6 | 13.5 | 19.6 | 46.1 | 115 | Does not straddle | ENERGY STAR |
| Keplerx KARC10RSVE1 | 10,000 | 18.6 | 13.5 | 19.6 | 46.1 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW101WA | 10,000 | 18.6 | 13.5 | 19.6 | 46.1 | 115 | Does not straddle | ENERGY STAR |
| Midea 1014634875 / MAW10RV1CCWT / MAW10RV1CWT / MAW10S1VWT-A +2 more | 10,000 | 18.6 | 13.5 | 19.6 | 46.1 | 115 | Does not straddle | ENERGY STAR |
| Noma 043-8814-4 | 8,000 | 18.9 | 14.6 | 21.5 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| Noma iQ 143-0087-4 | 8,000 | 18.9 | 14.6 | 21.5 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| Noma 043-8815-2 | 10,000 | 18.9 | 14.6 | 21.5 | 53.6 | 115 | Does not straddle | ENERGY STAR |
| Noma iQ 143-0088-2 | 10,000 | 18.9 | 14.6 | 21.5 | 53.6 | 115 | Does not straddle | ENERGY STAR |
| Hisense AAW12TW26 | 12,000 | 18.9 | 14.6 | 21.5 | 55.1 | 115 | Does not straddle | ENERGY STAR |
| Richmond RMV12A10A | 12,000 | 18.9 | 14.6 | 21.5 | 59.5 | 115 | Does not straddle | ENERGY STAR |
| Hisense AW1422TW1W | 14,000 | 18.9 | 14.6 | 21.5 | 58.9 | 115 | Does not straddle | ENERGY STAR |
| GE Appliances AWGP08W**# / AWP08P***# | 8,000 | 19 | 13.3 | 18.2 | 45.2 | 115 | Does not straddle | ENERGY STAR |
| GE Appliances AWHV10***# | 10,000 | 19 | 13.3 | 18.2 | 47.3 | 115 | Does not straddle | ENERGY STAR |
| BLACK+DECKER BDM08C | 8,000 | 19 | 13.6 | 18.5 | 42.1 | 115 | Does not straddle | ENERGY STAR |
| DuraSTAR DRWAC081XVB1 | 8,000 | 19 | 13.6 | 18.5 | 42.1 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW085WF1 | 8,000 | 19 | 13.6 | 18.5 | 42.1 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW08V1WBK / MAW08V1WWT / MAW08V1WWT-T | 8,000 | 19 | 13.6 | 18.6 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW08V1WBK-T / MWFUWA-08CRFN8-BCP0 | 8,000 | 19 | 13.6 | 18.5 | 44.1 | 115 | Does not straddle | ENERGY STAR |
| BLACK+DECKER BDM10C | 10,000 | 19 | 13.6 | 18.5 | 46.5 | 115 | Does not straddle | ENERGY STAR |
| DuraSTAR DRWAC101XVB1 | 10,000 | 19 | 13.6 | 18.5 | 46.5 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW105WF1 / FHWW106WF1 | 10,000 | 19 | 13.6 | 18.5 | 46.5 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW10RV1KWT / MAW10S1KWT-A / MAW10V1KYWT-S / MWFUWA-10CRFN8-BCP0 | 10,000 | 19 | 13.6 | 18.5 | 46.5 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW10V1WWT / MAW10V1WWT-T / MWEUWA-10CRFN8-BCP0 | 10,000 | 19 | 13.6 | 18.6 | 47.2 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV10000 | 10,000 | 19 | 13.6 | 18.5 | 46.5 | 115 | Does not straddle | ENERGY STAR |
| Seasons SW10VB1 | 10,000 | 19 | 13.6 | 18.5 | 46.5 | 115 | Does not straddle | ENERGY STAR |
| Vissani VAW10V1KWTS / VAWA10V4HWT | 10,000 | 19 | 13.6 | 18.5 | 46.5 | 115 | Does not straddle | ENERGY STAR |
| GE PWJV10W**# | 10,000 | 19 | 14.5 | 19.8 | 70.1 | 115 | Does not straddle | ENERGY STAR |
| GE Profile PWDV12W**# | 12,000 | 19 | 14.7 | 21.7 | 49.9 | 115 | Does not straddle | ENERGY STAR |
| GE Profile PWDV14W**# | 14,000 | 19 | 14.7 | 21.7 | 55.3 | 115 | Does not straddle | ENERGY STAR |
| GE Appliances AWGP12W**# / AWP12P***# | 11,000 | 19 | 15 | 20.5 | 47.6 | 115 | Does not straddle | ENERGY STAR |
| GE Appliances AWHV12***# | 12,000 | 19 | 15 | 20.5 | 53.2 | 115 | Does not straddle | ENERGY STAR |
| GE Appliances AWHV14***# | 14,000 | 19 | 15 | 20.5 | 56.2 | 115 | Does not straddle | ENERGY STAR |
| BLACK+DECKER BD12NWES | 12,000 | 19.1 | 14.6 | 21.8 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| ELEMENT EHWR12BE | 12,000 | 19.1 | 14.6 | 21.8 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW125WE1 | 12,000 | 19.1 | 14.6 | 21.8 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| Keplerx KARC12RSVE1 | 12,000 | 19.1 | 14.6 | 21.8 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW121WA | 12,000 | 19.1 | 14.6 | 21.8 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| Midea 1014634874 / MAW12RV1CWT / MAW12S1VWT-A / MAW12S1VWWT-T +2 more | 12,000 | 19.1 | 14.6 | 21.8 | 50.7 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW145WE1 | 14,000 | 19.1 | 14.6 | 21.8 | 56.3 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW06U1QWT | 6,000 | 19.2 | 13.5 | 22 | 50.7 | 115 | Straddles window | ENERGY STAR |
| Midea MAW06V1QWBL-T | 6,000 | 19.2 | 13.5 | 22 | 50.7 | 115 | Straddles windowsill | ENERGY STAR |
| Midea MAW06V1QWT / MAW06V1UBL / MAW06V1UWT / MWAUQB-06CRFN8-BCN11 | 6,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire Gallery GHWW085TF1 | 7,800 | 19.2 | 13.5 | 22 | 52.7 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW08U1KWT / MAW08U1KWT-A / MAW08U1KWT-M / MWFUQB-8CRFN8-BCN11 | 7,800 | 19.2 | 13.5 | 22 | 52.7 | 115 | Straddles window | ENERGY STAR |
| Midea MAW08V1KWT-A / MAW08V1KYWT-S | 7,800 | 19.2 | 13.5 | 22 | 52.7 | 115 | Does not straddle | ENERGY STAR |
| Century RXTS-81A | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Straddles window | ENERGY STAR |
| Comfort Aire RXTS-81A | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Straddles window | ENERGY STAR |
| Danby DAC080B7IWDB-6 / DAC080B8IWDB-6 | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Straddles window | ENERGY STAR |
| Frigidaire Gallery GHWQ083WC1 / GHWQ085WD1 | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Straddles window | ENERGY STAR |
| Frigidaire Gallery GHWW085TE1 | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Does not straddle | ENERGY STAR |
| Honeywell HAC-8I | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Does not straddle | ENERGY STAR |
| Hykolity ACB-2601 | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW08INV | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Straddles window | ENERGY STAR |
| Midea 1010451315 / 1014242943 / MAW08AV1QWT / MAW08AV1QWT-C +8 more | 8,000 | 19.2 | 13.5 | 22 | 54.3 | 115 | Straddles window | ENERGY STAR |
| Midea MAW08V1QWT-S / MAW08V1UWT / MAW08V1YWT-S / MAW08W1QWT +3 more | 8,000 | 19.2 | 13.5 | 22 | 53.2 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACU8000 / 1PACV8000 | 8,000 | 19.2 | 13.5 | 22 | 53.1 | 115 | Straddles window | ENERGY STAR |
| Century RXTS-101A | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Straddles window | ENERGY STAR |
| Comfort Aire RXTS-101A | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Straddles window | ENERGY STAR |
| Danby DAC100B8IWDB-6 | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Straddles window | ENERGY STAR |
| Frigidaire Gallery GHWQ103WC1 / GHWQ105WD1 | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Straddles window | ENERGY STAR |
| Frigidaire Gallery GHWW105TE1 / GHWW105TF1 | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Does not straddle | ENERGY STAR |
| Hykolity ACB-2602 | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW10INV | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Straddles window | ENERGY STAR |
| Midea 1010451479 / 1014264129 / MAW10U1KWT / MAW10U1KWT-A +8 more | 10,000 | 19.2 | 13.5 | 22 | 54.7 | 115 | Straddles window | ENERGY STAR |
| Midea MAW10V1UWT / MAW10W1QWT / MWAUQB-10CRFN8-BCN10 | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACU10000 / 1PACV10000 | 10,000 | 19.2 | 13.5 | 22 | 54 | 115 | Straddles window | ENERGY STAR |
| Century RXTS-121A | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Straddles window | ENERGY STAR |
| Comfort Aire RXTS-121A | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Straddles window | ENERGY STAR |
| Frigidaire Gallery GHWQ123WC1 / GHWQ125WD1 | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Straddles window | ENERGY STAR |
| Frigidaire Gallery GHWW125TE1 / GHWW125TF1 | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Does not straddle | ENERGY STAR |
| Hykolity ACB-2603 | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW12INV | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Straddles window | ENERGY STAR |
| Midea 1010451379 / 1014278205 / MAW12AV1QWT / MAW12AV1QWT-C +11 more | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Straddles window | ENERGY STAR |
| Midea MAW12AV1UWT-C / MAW12V1QWT-S / MAW12V1UWT / MAW12W1QWT +1 more | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW12U1KWT-M / MWAUQB-12CRFN8-BCP0 | 12,000 | 19.2 | 13.5 | 22 | 58.4 | 115 | Straddles windowsill | ENERGY STAR |
| Perfect aire 1PACU12000 / 1PACV12000 | 12,000 | 19.2 | 13.5 | 22 | 56.9 | 115 | Straddles window | ENERGY STAR |
| Windmill 08W2Wi | 8,000 | 19.3 | 13.3 | 22.5 | 61 | 115 | Does not straddle | ENERGY STAR |
| Windmill 10W2Wi | 10,000 | 19.3 | 13.3 | 22.5 | 63 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW08INV-HC | 8,000 | 19.4 | 13.9 | 22.2 | 56 | 115 | Straddles window | ENERGY STAR |
| Midea MAW08HV1CWT / MAW08HV1KWT-A / MWAUQB-08HRFN8-BCN11 | 8,000 | 19.4 | 13.9 | 22.2 | 56 | 115 | Does not straddle | ENERGY STAR |
| Midea MWAUQB-08HRFN8-BCL0 | 8,000 | 19.4 | 13.9 | 22.2 | 56 | 115 | Straddles window | ENERGY STAR |
| DuraSTAR DRWHPC121XVB1 | 12,000 | 19.4 | 13.9 | 22.2 | 59.5 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW12INV-HC | 12,000 | 19.4 | 13.9 | 22.2 | 58 | 115 | Straddles window | ENERGY STAR |
| LUBECK 57H-ID0-B12HRFN8BCL0 | 12,000 | 19.4 | 13.9 | 22.2 | 58 | 115 | Straddles window | ENERGY STAR |
| Midea MAW12HV1CWT / MAW12HV1CWT-A / MWAUQB-12HRFN8-BCL0 | 12,000 | 19.4 | 13.9 | 22.2 | 58 | 115 | Straddles window | ENERGY STAR |
| Midea MAW12HV1KWT-A / MWAUQB-12HRFN8-BCN4 | 12,000 | 19.4 | 13.9 | 22.2 | 59.5 | 115 | Does not straddle | ENERGY STAR |
| LG LW6023IVSM | 6,000 | 19.6 | 12.4 | 24.5 | 62 | 115 | Does not straddle | ENERGY STAR |
| LG LW8022IVSM | 8,000 | 19.6 | 12.4 | 24.5 | 63 | 115 | Straddles windowsill | ENERGY STAR |
| LG LW1022FVSM / LW1022IVSM | 10,000 | 19.6 | 12.4 | 24.5 | 63 | 116 | Straddles windowsill | ENERGY STAR |
| GE Profile PHNT10CCH1 | 10,300 | 19.7 | 12.8 | 28 | 80 | 115 | Straddles windowsill | ENERGY STAR |
| GE Profile PHNT12CCH1 | 12,200 | 19.7 | 12.8 | 28 | 80 | 115 | Straddles windowsill | ENERGY STAR |
| TCL T10WV3S / T10WV9S / T10WV9SB / W10WC72 +1 more | 10,000 | 19.8 | 15.2 | 21.5 | 49.6 | 115 | Straddles window | ENERGY STAR |
| TCL T12WV4S / T12WV9S / T12WV9SB / W12WC72 +1 more | 12,000 | 19.8 | 15.2 | 21.5 | 51.8 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW121CWX | 12,000 | 19.8 | 15.2 | 21.5 | 52.9 | 115 | Straddles window | ENERGY STAR |
| TCL T14WV9S / T14WV9SB / W14WC72 / W14WC72-B | 14,000 | 19.8 | 15.2 | 21.5 | 57.3 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW151CX | 14,000 | 19.8 | 15.2 | 21.5 | 57.3 | 115 | Straddles window | ENERGY STAR |
| GE PWJV14W**# | 14,000 | 20.2 | 15.1 | 21.3 | 70.1 | 115 | Does not straddle | ENERGY STAR |
| Hisense AALW08TW26 / AWL0826TW1W / HLAW0825TW | 8,000 | 20.3 | 14.6 | 20.7 | 51.2 | 115 | Straddles window | ENERGY STAR |
| Hisense AWUS1026TW | 10,000 | 20.3 | 14.6 | 20.7 | 55.1 | 115 | Straddles window | ENERGY STAR |
| Hisense AW-12TW1RZAU70 / AWUS1227TW | 11,500 | 20.3 | 14.6 | 20.5 | 56.2 | 115 | Straddles window | ENERGY STAR |
| Hisense 143-1306-8 / AHLW1225TW1W / AWL1225TW1W / LWCT12W25A +1 more | 12,000 | 20.3 | 14.6 | 20.7 | 55.1 | 115 | Straddles window | ENERGY STAR |
| Vissani VWL1225T | 12,000 | 20.3 | 14.6 | 20.7 | 55.1 | 115 | Straddles window | ENERGY STAR |
| GE Profile AHTR10ACH2 | 10,100 | 20.5 | 13.9 | 19.9 | 65 | 115 | Does not straddle | ENERGY STAR, GE (sizes) |
| TCL H6W4KW / T06WQ2S / W6WC72-BI / W6WC72-I | 6,000 | 20.7 | 13.4 | 19.3 | 51.6 | 115 | Straddles window | ENERGY STAR |
| DELLA 048-TL-W8KI / 048-TL-W8KI | 8,000 | 20.7 | 13.4 | 19.3 | 56.2 | 115 | Does not straddle | ENERGY STAR |
| Friedrich CCV08A10A | 8,000 | 20.7 | 13.4 | 19.3 | 56.2 | 115 | Does not straddle | ENERGY STAR |
| Ktaxon TIWC-08CRD1 | 8,000 | 20.7 | 13.4 | 19.3 | 56.2 | 115 | Does not straddle | ENERGY STAR |
| ROVSUN TIWC-08CRD1 / TIWC-08CRD1 | 8,000 | 20.7 | 13.4 | 19.3 | 56.2 | 115 | Does not straddle | ENERGY STAR |
| TCL T08WQ2S | 8,000 | 20.7 | 13.4 | 19.3 | 56.2 | 115 | Straddles window | ENERGY STAR |
| ZOKOP TIWC-08CRD1 | 8,000 | 20.7 | 13.4 | 19.3 | 56.2 | 115 | Does not straddle | ENERGY STAR |
| DELLA 048-TL-W10KI / 048-TL-W10KI | 10,000 | 20.7 | 13.4 | 19.3 | 57.8 | 115 | Does not straddle | ENERGY STAR |
| Friedrich CCV10A10A | 10,000 | 20.7 | 13.4 | 19.3 | 57.8 | 115 | Does not straddle | ENERGY STAR |
| Ktaxon TIWC-10CRD1 | 10,000 | 20.7 | 13.4 | 19.3 | 57.8 | 115 | Does not straddle | ENERGY STAR |
| ROVSUN TIWC-10CRD1 | 10,000 | 20.7 | 13.4 | 19.3 | 57.8 | 115 | Does not straddle | ENERGY STAR |
| TCL T10WQ2S | 10,000 | 20.7 | 13.4 | 19.3 | 57.8 | 115 | Straddles window | ENERGY STAR |
| ZOKOP TIWC-10CRD1 | 10,000 | 20.7 | 13.4 | 19.3 | 57.8 | 115 | Does not straddle | ENERGY STAR |
| DELLA 048-TL-W12KI / 048-TL-W12KI | 12,000 | 20.7 | 13.4 | 19.3 | 58.6 | 115 | Does not straddle | ENERGY STAR |
| Friedrich CCV12A10A | 12,000 | 20.7 | 13.4 | 19.3 | 58.6 | 115 | Does not straddle | ENERGY STAR |
| Ktaxon TIWC-12CRD1 | 12,000 | 20.7 | 13.4 | 19.3 | 58.6 | 115 | Does not straddle | ENERGY STAR |
| ROVSUN TIWC-12CRD1 | 12,000 | 20.7 | 13.4 | 19.3 | 58.6 | 115 | Does not straddle | ENERGY STAR |
| TCL T12WQ2S | 12,000 | 20.7 | 13.4 | 19.3 | 58.6 | 115 | Straddles window | ENERGY STAR |
| ZAFRO A8503W-12K | 12,000 | 20.7 | 13.4 | 19.3 | 58.6 | 115 | Does not straddle | ENERGY STAR |
| ZOKOP TIWC-12CRD1 | 12,000 | 20.7 | 13.4 | 19.3 | 58.6 | 115 | Does not straddle | ENERGY STAR |
| HOUSE KOBO KOBOGJC08BU | 8,100 | 21 | 13 | 18 | 60.6 | 115 | Straddles window | ENERGY STAR |
| GREE GJC08BU-A6DRNJ2A | 8,300 | 21 | 13 | 18 | 60.6 | 115 | Straddles window | ENERGY STAR |
| GREE GJC10BU-A6DRNJ2A | 10,000 | 21 | 13 | 18 | 65 | 115 | Straddles window | ENERGY STAR |
| HOUSE KOBO KOBOGJC10BU | 10,000 | 21 | 13 | 18 | 65 | 115 | Straddles window | ENERGY STAR |
| GREE GJC12BU-A6DRNJ2A | 11,500 | 21 | 13 | 18 | 65 | 115 | Straddles window | ENERGY STAR |
| HOUSE KOBO KOBOGJC12BU | 11,500 | 21 | 13 | 18 | 65 | 115 | Straddles window | ENERGY STAR |
| BLACK+DECKER BDM12C | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| Brothers 102073 | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| Danby DAC120ECBIWDB | 12,000 | 21.7 | 14.7 | 19 | 50.9 | 115 | Does not straddle | ENERGY STAR |
| DuraSTAR DRWAC121XVB1 | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW125WF1 / FHWW126WF1 | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| Insignia NS-AC12WWH5-C | 12,000 | 21.7 | 14.7 | 19 | 50.9 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW12RV1KWT / MAW12S1KWT-A / MAW12V1WBK / MAW12V1WBK-T +5 more | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| OMNI MAX OWH121CV4A | 12,000 | 21.7 | 14.7 | 19 | 50.9 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV12000 | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| Seasons SW12VB1 | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| Vissani VAW12V1KWTS / VAWA12V4HWT | 12,000 | 21.7 | 14.7 | 19 | 51.8 | 115 | Does not straddle | ENERGY STAR |
| BLACK+DECKER BDM14C | 14,000 | 21.7 | 14.7 | 19 | 56.9 | 115 | Does not straddle | ENERGY STAR |
| Danby DAC140EBIBDB | 14,000 | 21.7 | 14.7 | 19 | 56 | 115 | Does not straddle | ENERGY STAR |
| ELEMENT EHWR14BE | 14,000 | 21.7 | 14.7 | 19 | 56 | 115 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW145WF1 / FHWW146WF1 | 14,000 | 21.7 | 14.7 | 19 | 56.9 | 115 | Does not straddle | ENERGY STAR |
| Keplerx KARC14RSVE1 | 14,000 | 21.7 | 14.7 | 19 | 56 | 115 | Does not straddle | ENERGY STAR |
| Keystone KSTAW141WA | 14,000 | 21.7 | 14.7 | 19 | 56 | 115 | Does not straddle | ENERGY STAR |
| Midea 1014634880 / MAW14R1VWT / MAW14RV1CCWT / MAW14RV1CWT +8 more | 14,000 | 21.7 | 14.7 | 19 | 56 | 115 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV14000 | 14,000 | 21.7 | 14.7 | 19 | 56.9 | 115 | Does not straddle | ENERGY STAR |
| Seasons SW14VB1 | 14,000 | 21.7 | 14.7 | 19 | 56.9 | 115 | Does not straddle | ENERGY STAR |
| Vissani VAWA14V4HWT | 14,000 | 21.7 | 14.7 | 19 | 56 | 115 | Does not straddle | ENERGY STAR |
| Midea MAW14S1VWWT-T | 14,000 | 22 | 14.7 | 19 | 56 | 115 | Does not straddle | ENERGY STAR |
| TCL H8W4MW | 8,000 | 23 | 14 | 18.8 | 57.3 | 115 | Does not straddle | ENERGY STAR |
| TCL H10W4MW | 10,000 | 23 | 14 | 18.8 | 58.4 | 115 | Does not straddle | ENERGY STAR |
| TCL H12W4MW | 12,000 | 23 | 14 | 18.8 | 59.5 | 115 | Does not straddle | ENERGY STAR |
| LG LW8024IVSM | 8,500 | 23.6 | 15 | 28.8 | 85 | 115 | Does not straddle | ENERGY STAR |
| LG LW1222IVSM | 12,000 | 23.6 | 15 | 28.8 | 85 | 115 | Straddles window | ENERGY STAR |
| LG LW1224IVSM | 12,000 | 23.6 | 15 | 28.8 | 85 | 115 | Does not straddle | ENERGY STAR |
| LG LW1522FVSM / LW1522IVSM | 14,000 | 23.6 | 15 | 28.8 | 85 | 115 | Straddles windowsill | ENERGY STAR |
| Frigidaire FHWW185WE2 | 18,000 | 23.6 | 17.9 | 25.4 | 95.9 | 230 | Does not straddle | ENERGY STAR |
| Hisense AW1823TW3W | 18,000 | 23.6 | 17.9 | 25.3 | 84.9 | 230 | Does not straddle | ENERGY STAR |
| Keplerx KBRC18RSVE2 | 18,000 | 23.6 | 17.9 | 25.4 | 95.9 | 230 | Does not straddle | ENERGY STAR |
| Keystone KSTAW182WA | 18,000 | 23.6 | 17.9 | 25.4 | 95.9 | 230 | Does not straddle | ENERGY STAR |
| Midea MAW18R2VWT / MAW18R2VWT / MAW18RV1CWT / MAW18S2VWT-A +1 more | 18,000 | 23.6 | 17.9 | 25.4 | 95.9 | 230 | Does not straddle | ENERGY STAR |
| Hisense AW2223TW3W | 22,000 | 23.6 | 17.9 | 25.3 | 87.1 | 230 | Does not straddle | ENERGY STAR |
| Comfort Aire RADS-253R03 | 24,000 | 23.6 | 17.9 | 25.4 | 103 | 230 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW245WE2 | 24,000 | 23.6 | 17.9 | 25.4 | 103 | 230 | Does not straddle | ENERGY STAR |
| Keplerx KBRC24RSVE2 | 24,000 | 23.6 | 17.9 | 25.4 | 103 | 230 | Does not straddle | ENERGY STAR |
| Keystone KSTAW242WA | 24,000 | 23.6 | 17.9 | 25.4 | 103 | 230 | Does not straddle | ENERGY STAR |
| Midea MAW24R2VWT / MAW24RV1CWT / MAW24S2VWT-A / MAW24S2YWT-S +3 more | 24,000 | 23.6 | 17.9 | 25.4 | 103 | 230 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV25000E | 24,000 | 23.6 | 17.9 | 25.4 | 103 | 230 | Does not straddle | ENERGY STAR |
| Sea Breeze WA324ZREB | 24,000 | 23.6 | 17.9 | 25.4 | 103 | 230 | Does not straddle | ENERGY STAR |
| Whirlpool WHAW081INV | 8,000 | 24.2 | 14.5 | 20.3 | 56.2 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW101INV | 10,000 | 24.2 | 14.5 | 20.3 | 57.3 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW121INV | 12,000 | 24.2 | 14.5 | 20.3 | 58.4 | 115 | Straddles window | ENERGY STAR |
| Hykolity ACB-2621 | 8,000 | 24.2 | 16.1 | 20.7 | 61.7 | 115 | Straddles window | ENERGY STAR |
| Ktaxon KXTIW-08CRD1 | 8,000 | 24.2 | 16.1 | 20.7 | 61.7 | 115 | Straddles window | ENERGY STAR |
| ROVSUN RVTIW-08CRD1 | 8,000 | 24.2 | 16.1 | 20.7 | 61.7 | 115 | Straddles window | ENERGY STAR |
| TCL H8W4KW / H8W4KW-CA / T08WQ2S | 8,000 | 24.2 | 16.1 | 20.7 | 61.7 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW-081IN | 8,000 | 24.2 | 16.1 | 20.7 | 61.7 | 115 | Straddles window | ENERGY STAR |
| Hykolity ACB-2622 | 10,000 | 24.2 | 16.1 | 20.7 | 63.9 | 115 | Straddles window | ENERGY STAR |
| Ktaxon KXTIW-10CRD1 | 10,000 | 24.2 | 16.1 | 20.7 | 63.9 | 115 | Straddles window | ENERGY STAR |
| PHILODECO PIWC-10CRD1(ES) | 10,000 | 24.2 | 16.1 | 20.7 | 63.9 | 115 | Straddles window | ENERGY STAR |
| ROVSUN RVTIW-10CRD1 | 10,000 | 24.2 | 16.1 | 20.7 | 63.9 | 115 | Straddles window | ENERGY STAR |
| TCL H10W4KW / H10W4KW-CA / T10WQ2S | 10,000 | 24.2 | 16.1 | 20.7 | 63.9 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW-101IN | 10,000 | 24.2 | 16.1 | 20.7 | 63.9 | 115 | Straddles window | ENERGY STAR |
| Hykolity ACB-2623 | 12,000 | 24.2 | 16.1 | 20.7 | 65 | 115 | Straddles window | ENERGY STAR |
| Ktaxon KXTIW-12CRD1 | 12,000 | 24.2 | 16.1 | 20.7 | 65 | 115 | Straddles window | ENERGY STAR |
| PHILODECO PIWC-12CRD1(ES) | 12,000 | 24.2 | 16.1 | 20.7 | 65 | 115 | Straddles window | ENERGY STAR |
| ROVSUN RVTIW-12CRD1 | 12,000 | 24.2 | 16.1 | 20.7 | 65 | 115 | Straddles window | ENERGY STAR |
| TCL H12W4KW / H12W4KW-CA / T12WQ2S | 12,000 | 24.2 | 16.1 | 20.7 | 65 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW-121IN | 12,000 | 24.2 | 16.1 | 20.7 | 65 | 115 | Straddles window | ENERGY STAR |
| Midea MAH09B1AGR / MAH09H1AGR / MAH09N1AGR / MAH09S1AGR +3 more | 9,500 | 25 | 20.9 | 41.2 | 129 | 115 | Straddles windowsill | ENERGY STAR |
| Gradient CCHP11 | 9,300 | 25.3 | 24 | 37.3 | 140 | 120 | Straddles window | ENERGY STAR |
| TCL T15WQ2S | 15,000 | 25.4 | 16.9 | 26.4 | 92.6 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW151INV | 15,000 | 25.4 | 16.9 | 26.4 | 90.4 | 115 | Straddles window | ENERGY STAR |
| TCL T18WQ2S | 18,000 | 25.4 | 16.9 | 26.4 | 95.9 | 230 | Straddles window | ENERGY STAR |
| Whirlpool WHAW182INV / WHHW182INV | 18,000 | 25.4 | 16.9 | 26.4 | 99.2 | 230 | Straddles window | ENERGY STAR |
| TCL T24WQ2S | 24,000 | 25.4 | 16.9 | 26.4 | 99.2 | 230 | Straddles window | ENERGY STAR |
| Whirlpool WHAW242INV / WHHW242INV | 24,000 | 25.4 | 16.9 | 26.4 | 101.4 | 230 | Straddles window | ENERGY STAR |
| BLACK+DECKER BDM18C | 18,000 | 25.4 | 17.9 | 23.6 | 94.4 | 230 | Does not straddle | ENERGY STAR |
| Brothers 102387 | 18,000 | 25.4 | 17.9 | 23.6 | 94.4 | 230 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW185WF2 | 18,000 | 25.4 | 17.9 | 23.6 | 94.4 | 230 | Does not straddle | ENERGY STAR |
| Midea MAW18RV1KWT / MAW18S2KWT-A / MWCUWH-18CRFN8-MCP0 | 18,000 | 25.4 | 17.9 | 23.6 | 94.4 | 230 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV18000 | 18,000 | 25.4 | 17.9 | 23.6 | 94.4 | 230 | Does not straddle | ENERGY STAR |
| Seasons SW18V2 | 18,000 | 25.4 | 17.9 | 23.6 | 94.4 | 230 | Does not straddle | ENERGY STAR |
| Frigidaire FHWW245WF2 | 24,000 | 25.4 | 17.9 | 23.6 | 101.4 | 230 | Does not straddle | ENERGY STAR |
| Midea MAW24RV1KWT / MAW24S2KWT-A / MAW24V2KYWT-S / MWCUWH-24CRFN8-MCM8 | 24,000 | 25.4 | 17.9 | 23.6 | 101.4 | 230 | Does not straddle | ENERGY STAR |
| Perfect aire 1PACV24000 | 24,000 | 25.4 | 17.9 | 23.6 | 101.4 | 230 | Does not straddle | ENERGY STAR |
| Seasons SW24V2 | 24,000 | 25.4 | 17.9 | 23.6 | 101.4 | 230 | Does not straddle | ENERGY STAR |
| Friedrich KCVS08B10A | 8,700 | 25.9 | 15.9 | 29 | 100 | 115 | Does not straddle | ENERGY STAR |
| Kuhl KCVS08B10B | 8,700 | 25.9 | 15.9 | 29 | 70 | 115 | Straddles windowsill | ENERGY STAR |
| Friedrich KHVS10B11A | 10,200 | 25.9 | 15.9 | 29 | 105 | 115 | Does not straddle | ENERGY STAR |
| Kuhl+ KHVS10B11B | 10,600 | 25.9 | 15.9 | 29 | 105 | 115 | Straddles windowsill | ENERGY STAR |
| Kuhl KCVS12B10B | 12,300 | 25.9 | 15.9 | 29 | 110 | 115 | Straddles windowsill | ENERGY STAR |
| Friedrich KCVS12B10A | 12,500 | 25.9 | 15.9 | 29 | 110 | 115 | Does not straddle | ENERGY STAR |
| Friedrich KHVS12B33A | 12,600 | 25.9 | 15.9 | 29 | 115 | 230 | Does not straddle | ENERGY STAR |
| Kuhl+ KHVS12B33B | 12,600 | 25.9 | 15.9 | 29 | 115 | 230 | Straddles windowsill | ENERGY STAR |
| Friedrich KCVS12B30A | 12,700 | 25.9 | 15.9 | 29 | 110 | 230 | Does not straddle | ENERGY STAR |
| Kuhl KCVS12B30B | 12,700 | 25.9 | 15.9 | 29 | 110 | 230 | Straddles windowsill | ENERGY STAR |
| Kuhl KCVS16B30B | 15,400 | 25.9 | 15.9 | 29 | 110 | 230 | Straddles windowsill | ENERGY STAR |
| Friedrich KCVS16B30A | 16,200 | 25.9 | 15.9 | 29 | 110 | 230 | Does not straddle | ENERGY STAR |
| Friedrich KCVM14B10A | 13,900 | 25.9 | 17.9 | 29 | 120 | 115 | Does not straddle | ENERGY STAR |
| Friedrich KCVM14B10B | 14,100 | 25.9 | 17.9 | 29 | 70 | 115 | Straddles windowsill | ENERGY STAR |
| Friedrich KCVM18B30A | 19,100 | 25.9 | 17.9 | 29 | 130 | 230 | Does not straddle | ENERGY STAR |
| Kuhl KCVM18B30B | 20,900 | 25.9 | 17.9 | 29 | 130 | 230 | Straddles windowsill | ENERGY STAR |
| Friedrich KHVM24B34A | 22,900 | 25.9 | 17.9 | 29 | 135 | 230 | Does not straddle | ENERGY STAR |
| Kuhl KCVM24B30B | 23,100 | 25.9 | 17.9 | 29 | 130 | 230 | Straddles windowsill | ENERGY STAR |
| Friedrich KCVM24B30A | 23,200 | 25.9 | 17.9 | 29 | 130 | 230 | Does not straddle | ENERGY STAR |
| GREE GJH09BW-A6DRNL1A / GJH09BW-A6DRNL1B | 9,300 | 26 | 15.3 | 27.5 | 116 | 115 | Straddles window | ENERGY STAR |
| Kinghome KHWA09IN | 9,300 | 26 | 15.3 | 27.5 | 116 | 115 | Straddles window | ENERGY STAR |
| Friedrich CCV15A10A | 15,000 | 26 | 15.3 | 27.5 | 102 | 115 | Straddles window | ENERGY STAR |
| TCL H15W4KW-CA / H15W4KW / T15WQ2S | 15,000 | 26 | 15.3 | 27.5 | 102 | 115 | Straddles window | ENERGY STAR |
| Friedrich CCV18A30A | 18,000 | 26 | 15.3 | 27.5 | 116 | 230 | Straddles window | ENERGY STAR |
| HEMA DS-2W1822CI | 18,000 | 26 | 15.3 | 27.5 | 116 | 230 | Straddles window | ENERGY STAR |
| TCL H18W4KW / H18W4KW-CA / T18WQ2S | 18,000 | 26 | 15.3 | 27.5 | 116 | 230 | Straddles window | ENERGY STAR |
| Friedrich CCV24A30A | 24,000 | 26 | 15.3 | 27.5 | 122 | 230 | Straddles window | ENERGY STAR |
| TCL H24W4KW / H24W4KW-CA / T24WQ2S | 24,000 | 26 | 15.3 | 27.5 | 122 | 230 | Straddles window | ENERGY STAR |
| LG LW1822IVSM | 18,000 | 26 | 17.7 | 30.7 | 112 | 230 | Does not straddle | ENERGY STAR |
| LG LW2422IVSM(208V) / LW2422IVSM(230V) | 23,500 | 26 | 17.7 | 30.7 | 112 | 208 | Straddles windowsill | ENERGY STAR |
| Friedrich WCVT10B30B | 10,000 | 26.5 | 15.8 | 21 | 110 | 115 | Does not straddle | ENERGY STAR |
| Friedrich KHVL28B35A | 28,200 | 28 | 20.2 | 35.5 | 160 | 230 | Does not straddle | ENERGY STAR |
| Kuhl+ KHVL28B35B | 28,300 | 28 | 20.2 | 35.5 | 160 | 230 | Straddles windowsill | ENERGY STAR |
| Friedrich KCVL28B30A | 28,900 | 28 | 20.2 | 35.5 | 155 | 230 | Does not straddle | ENERGY STAR |
| Kuhl KCVL28B30B | 28,900 | 28 | 20.2 | 35.5 | 155 | 230 | Straddles windowsill | ENERGY STAR |
| Kuhl KCVL36B30B | 33,000 | 28 | 20.2 | 35.5 | 155 | 230 | Straddles windowsill | ENERGY STAR |
| Friedrich KCVL36B30A | 34,100 | 28 | 20.2 | 35.5 | 155 | 230 | Does not straddle | ENERGY STAR |
| TCL H12W4KWH / H12W4KWH-CA / KCR-35/YXRDBp(E1/6)(080002) | 12,000 | 30 | 20.1 | 28.8 | 94.7 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW-151IN | 15,000 | 30 | 20.7 | 28.8 | 102.5 | 115 | Straddles window | ENERGY STAR |
| Whirlpool WHAW-181IN | 18,000 | 30 | 20.7 | 28.8 | 105.8 | 230 | Straddles window | ENERGY STAR |
| Whirlpool WHAW-241IN | 24,000 | 30 | 20.7 | 28.8 | 115.7 | 230 | Straddles window | ENERGY STAR |
Maker window minimums vs cabinet size
The cabinet size is not the window size. These 15 units have a published window range, and the window minimum is always bigger than the cabinet. Cabinet sizes come from the same maker document, except for TCL and the Midea U, where they come from ENERGY STAR.
| Unit | Btu | Cabinet width | Cabinet height | Window width the maker supports | Minimum clear height | Extra width needed | Source |
|---|---|---|---|---|---|---|---|
| TCL 5,000 Btu (T05WV9M) | 5,000 | 16 in | 12.5 in | 23 to 36 in | 14.5 in | 7 in | Maker, ENERGY STAR |
| Frigidaire FHWW063WB | 6,000 | 18.5 in | 13 in | 24 to 36 in | 14 in | 5.5 in | Maker |
| Midea MAW08V1QWT (U) | 8,000 | 19.2 in | 13.5 in | 22 to 36 in | 13.75 in | 2.8 in | Maker, ENERGY STAR |
| TCL 8,000 Btu (T08WV9S) | 8,000 | 18.6 in | 13.3 in | 23 to 36 in | 14.5 in | 4.4 in | Maker, ENERGY STAR |
| Frigidaire FHWW083WB | 8,000 | 18.5 in | 13 in | 24 to 36 in | 14 in | 5.5 in | Maker |
| Frigidaire Gallery GHWQ083WC | 8,000 | 19.5 in | 14 in | 24 to 38.8 in | 14 in | 4.5 in | Maker |
| Frigidaire FHWW103WB | 10,000 | 19 in | 14.5 in | 25 to 36 in | 15.5 in | 6 in | Maker |
| TCL 10,000 Btu (T10WV9S) | 10,000 | 19.8 in | 15.2 in | 26 to 36 in | 16 in | 6.2 in | Maker, ENERGY STAR |
| GE Profile AHTR10AC | 10,100 | 20.5 in | 13.9 in | 26.375 to 40.5 in | 14.0625 in | 5.9 in | Maker |
| Frigidaire Gallery GHWQ123WC | 12,000 | 19.5 in | 14 in | 24 to 38.8 in | 14 in | 4.5 in | Maker |
| Frigidaire FHWW123WB | 12,000 | 19 in | 14.5 in | 25 to 36 in | 15.5 in | 6 in | Maker |
| Friedrich CCW15B10B | 15,000 | 23.6 in | 17.9 in | 28 to 41 in | 20 in | 4.4 in | Maker |
| Frigidaire FHWW153WB | 15,100 | 24 in | 18 in | 28 to 40.5 in | 18.5 in | 4 in | Maker |
| Friedrich CCW18B30B | 18,000 | 23.6 in | 17.9 in | 28 to 41 in | 20 in | 4.4 in | Maker |
| Friedrich CCW24B30B | 24,000 | 26.4 in | 18.8 in | 30 to 41 in | 21 in | 3.6 in | Maker |
TCL's chart covers its units from 5,000 to 24,000 Btu: 23 to 36 inch windows and 14.5 inches of height up to 8,000 Btu, 26 to 36 inches and 16 inches at 10,000 and 12,000 Btu, and up to 41 inches wide and 19.5 inches high at 22,000 and 24,000 Btu. Midea asks for a clear 13.75 inch opening under the lower sash for its U unit. Friedrich's minimum height for the Chill Premier is the vertical clearance in its manual.
Next step
Before you buy, open the installation guide for the exact model and compare its minimum window width and height with your measurements.
Common questions
How much wider than the air conditioner does my window need to be?
More than the cabinet. In the 15 maker examples we checked, the smallest window was 2.8 to 7 inches wider than the cabinet, because the side panels and brackets need room. Use the minimum window width in the installation guide for your exact model.
Can I fit one in a window narrower than the maker minimum?
TCL says most of its units can go in narrower windows without the side panels that come in the box, and points to each model's installation instructions for the true minimum. You then have to seal the gaps yourself.
What about casement and sliding windows?
The maker charts here are for double-hung windows that slide up: TCL says its window units are designed for a standard double-hung window, and Midea's U manual is written for double-hung windows too. For a sliding or casement window, check that the manual lists your window type. ENERGY STAR's data has a casement field, but it reads None for every current model.
Do I need to check the voltage too?
Yes. 53 of the 299 rows below run on 230 V or 208 V and need a matching outlet. The rest run on 115 V or 120 V.
Method
- Cabinet sizes. Height, width, depth, weight, capacity, voltage and mounting type from ENERGY STAR's certified room air conditioner data (dataset 5xn2-dv4h), window types only, read through the open data API on 17 October 2026.
- Grouping. Model numbers from one brand with the same cabinet, capacity and mounting type share a row.
- Window minimums. Read by hand from TCL's support chart, Frigidaire spec sheets and the Friedrich and Midea manuals. Cabinet sizes come from the same document, or from ENERGY STAR for TCL and the Midea U.
- Filter. The calculator keeps cabinets narrower than your window and shorter than your clear opening. That is a first check only, because each maker's window minimum is larger than the cabinet.
- Not covered. Window sill depth, storm windows, window guards and weight limits of the sill. Models that are not ENERGY STAR certified are not in the table.
Sources
- US EPA, ENERGY STAR Certified Room Air Conditioners (dataset 5xn2-dv4h), window types only, read through the open data API on 17 October 2026; each row links its record, read 2026-10-17
- TCL support, What size window do I need? (window width and minimum height by Btu), read 2026-10-17
- Frigidaire and Frigidaire Gallery spec sheets, Friedrich Chill Premier CCW manual and Midea MAW08V1QWT manual (PDFs), and the GE Profile AHTR10AC product page (read 17 October 2026), each linked in the table, read 2026-10-17
- Our window AC maker requirements dataset, CSV
- Our window AC dimensions dataset, CSV
Changes
- : Corrected the GE Profile AHTR10ACH2 row: ENERGY STAR lists it as 10.6 inches wide, but GE's AHTR10AC page (read 17 October 2026) gives 20.52 inches, so the table now uses GE's sizes and the GE window range is added to the maker table.
- : Published. 510 ENERGY STAR window models in 299 cabinet sizes, read from the open data API on 17 October 2026.
